Integral profile welding bed,The beam is a large square tube welding structure ,After high temperature annealing Rough processing and after secondary vibration aging treatment finishing processing
Loading material is conveniently operate
Famous fiber laser head for special cutting and capacitive non-contact high automatic tracking system
1000W high configuration Servo motor, reducer, bevel gear rack, guide rail and other high-precision transmission parts adopt German , Taiwan, Japan and other famous brand and 700W Standard configuration adopt Taiwan, China domestic first-line brand products
Reasonable layout and high integration design in small floor space
Electric and pneumatic system also adopt international brand series products
Auxiliary equipment (optional) air filtration system, stabilized voltage power supply, air compressor

Model No.	:	GS-3015
Cutting Nozzle Shape	:	Ring Type
Cutting Thickness	:	<12mm
Voltage	:	AC380V
Laser Power	:	700W/1000W/2000W Optional
Transport Package	:	Packed in Piaywood
Control Mode	:	CNC
Cutting Width	:	<3000mm
Cutting Speed	:	0-5000mm/Min
Gas	:	Oxygen, Nitrogen
